FlexRadio FLEX-6400M ATU ME ANTENNA TUNER-SDR Transceiver – ΠΛΗΡΩΜΗ ΑΠΟ 3 ΕΩΣ 60 ΔΟΣΕΙΣ ΧΩΡΙΣ ΠΙΣΤΩΤΙΚΉ ΚΑΡΤΑ

4,200.00

The FLEX-6400M ATU integrates all FLEX-6400 capabilities with a stunning 8-inch 1920 x 1200 IPS WUXGA touchscreen display and ergonomic controls to deliver a high-performance Software Defined Radio with a traditional radio interface. It delivers unmatched band awareness from an integrated display while providing an external connection for an HDMI compatible 1920 x 1200 resolution monitor for maximum spectral visibility. Influenced by top contest/DX operators, its symmetrical and independent dual VFO controls are strategically placed to provide maximum productivity for all types of operation. It’s completely self-contained so just plug it in and operate — no PC, network, or learning curve required.

Κατόπιν παραγγελίας

— OR  —

Κωδικός προϊόντος: 018844

Περιγραφή

The FLEX-6400M offers the latest direct sampling SDR technology at an economical price for the general HF/6m operator yet it offers great performance for chasing DX and contesting.

With a PC, laptop, or Mac client you can utilize up to two 7 MHz spectrum/waterfall displays and independent receivers to revolutionize your view of the bands. Its two receivers can be placed simultaneously on any band and mode with instant QSY between VFOs. Digital mode operation is a dream with no sound cards, cables, or boxes needed.

FlexRadio’s industry-leading SmartSDR™ software offers compatibility across the entire FLEX-6000 Signature Series family to deliver continuous leveraged software enhancement. And you can use the latest SmartLink™ technology to access your radio virtually anywhere from any SmartSDR compatible client with only a login and password — even your iPhone.

* Mac OSX SmartSDR software is provided by third-party vendors*

Features

  • 100W PEP HF-6m operation
  • All modes/all bands
  • Integrated Remote Operation with Maestro, PC/ Laptop, Mac, iPad® or iPhone®
  • 2 Independent Band / Mode Receivers
  • Full Duplex Cross-Band Operation
  • Transverter Port
  • Receive-Only Port
  • Direct Sampling SDR 122.88 Msps – 16 bit
  • 115 dB 2kHz RMDR
  • >155 dB Dynamic Range
  • Optional Antenna Tuner
  • 10 MHz Reference Input
  • Optional GPSDO Option for ultra high frequency precision and accuracy
  • Optional MARS/CAP/SHARES TX Expansion Module

All-in-One SDR includes all the features of the FLEX-6400 plus

  • Spectacular 8-Inch, 1920 X 1200 IPS Integrated Display
  • Touch Tune, Zoom, Pan Controls At Your Fingertips
  • Ergonomically Optimized Controls With Full Dual VFO
  • Up To 7MHz Spectrum / Waterfall Bandwidth
  • Real-Time Spectrum / Waterfall
  • External Display Output – Full 1920 X 1200 Resolution
  • Internal Speaker

Full Specifications

Receiver

  • Independent Band/Mode Receivers (Max): 2
  • 1/2 kHz Reciprocal Mixing Dynamic Range (RMDR): 110/115 dB
  • ADC Bits/Sampling Rate: 16/122.88 Msps
  • Frequency Coverage: 30 kHz-54 MHz
  • Amateur Band Preselectors: 3rd Order
  • Cable-less Digital Audio (DAX/DAX IQ) Channels: 2/2
  • Receive Only Ports (Base/Including XVTR Port): 1/2
  • Full Duplex RX/TX Operation

Spectrum/Waterfall

  • Internal Touch Panel Display Size Diagonal: 8-inch (6400M)
  • Integrated Display Resolution: 1920×1200 (6400M)
  • External Display Resolution/Connection: 1920×1200/HDMI (6400M)
  • Spectrum/Waterfall Displays (Max): 2
  • Spectrum/Waterfall BW (Min/Max): 5 kHz to 7MHz
  • Spectrum Dynamic Range (Max Zoom In): >145 dB
  • Spectrum Resolution Bandwidth (Min): 5.85 Hz/px

Transmitter

  • 160m-6m Transmitter Output: 1-100W(25W AM)
  • Harmonic Suppression (Typ): < -60 dBc
  • Transverter Ports: 1
  • Transverter Frequency Coverage/Power: 100 kHz – 54 MHz/0 to +10 dBm
  • Optional Integrated Automatic Antenna Tuner Range: 3:1 SWR
  • Optional Continuous MARS/CAP Coverage with Extended Transmit Filter

General

  • Modes1 SSB, CW, AM, SAM, FM, RTTY, DIGITAL
  • Integrated Remote Operation (SmartLink)
  • Maestro, PC, Mac, iPhone, & iPad Client Options
  • Internal Speaker/Power 2W Class D (6400M)
  • Frequency Stability (0C – 50C) 0.5ppm (TCXO)
  • GPS Disciplined Oscillator Optional 5 x 10-12 Over 24 Hours
  • External 10MHz Reference Input
  • Power Supply Requirements 13.8 VCDC +/- 15% (14 VDC Nom)
  • Dimensions 6.74″H (17.1 cm) x 14″W (35.6 cm) x 13.25″D (33.7 cm)

Simply Beautiful

  • No PC required to operate the FLEX-6400M
  • 8 inch 1920 x 1200 IPS Display
  • Up to two independent receivers
  • Up to two 7MHz spectrum displays
  • Optimized workflow
  • Ergonomically spaced / single-function controls

Plug & Play Remote**

  • No complex setup required
  • Operate anywhere, any time
  • Use a Maestro, Mac, iPad, iPhone or Laptop
  • Across the country or across the world
  • Anywhere, Anytime, From Any Of These Devices:

With SmartLink and a FLEX-6400M, you can operate your radio from almost anywhere! Just take an iPhone, iPad, Laptop, or Maestro with you and instantly connect to your radio with virtually no setup required.

Best in Class Performance

  • 115db RMDR
  • No listening fatigue
  • Ultra-Low Phase Noise
  • Full Break-in QSK CW
  • Brick Wall Filters
  • Stunning transmit audio

Backed by an Amazing Suite of Software

  • SmartSDR for the M Model Radio
  • SmartSDR for Windows
  • SmartSDR for Mac
  • SmartSDR for iOS
  • SmartSDR CAT
  • DAX

*A PC is required for use of 3rd party software such as loggers and digital modes programs.
**SmartLink Remote Requires SmartSDR V2.x License or Later. Requires an Internet connection.
